AutoPlay3

AutoPlay 3 is the all-in-one automation system with advanced functional characteristics. The system offers multi-channel broadcast with capability of news blocks playback and insertion of advertizing.

Software modules: CaptureAir

Functions

  • Multi-channel playout automation
  • Multi-channel recording to server in various modes (including TimeDelay technology)
  • Broadcast graphics with link to the main playlist and without by means of built-in graphics system
  • HD/SD Up/Down converting by each input and output channel
  • Metadata storage in multi-user database with quick search and access
  • System as run logging with set level of deteils
  • Users and groups rights for mediadata and its operation access management

Features

  • All-in-one automation system:
    • Integrated Azimuth video server
    • Integrated database
    • Integrated audio/video Live Switcher
    • Built-in subsystem to control external devices
    • Built-in broadcast graphics system
    • Built-in HD/SD Up/Down converter for each input and output channel and IP streaming
  • Playout:
    • SD: 720х576, 50i, video PAL/YUV/SDI, audio AA/ AES/SDI Emb.
    • HD: 1920х1080, 50i, video HD-SDI, audio HD-SDI Emb./AES
    • IP: MPEG4 part 10 (H.264)/ MPEG2
    • Monitoring of videoserver inputs/outputs by IP
  • Automatic execution of two-level Air playlist with the following features:
    • Clips and blocks playback from the videoserver
    • Media playback from VTR
    • Live clips with control of external Air switcher
    • Live clips with the use of Live Switcher (passthrough mode)
    • Playback of files that are in process of capture, import
    • Secondary events execution: graphics overlay, GPI signals output, main event recording
    • Multiple channel output from single playlist with trascoding: HD-SDI, SD-SDI, HD-IP, SD-IP channels in various combinations
  • Advanced videoserver control features:
    • Control of several playback channels from single client module
    • Local and network operation of all client modules
  • Ability to manually disconnect control station leaving video server to continue playback
  • Ability to continue playback from video servers even if the control module is disconnected due to the network failure
  • Standby clip technology
  • Control modules recovery at any network workstation
  • Advanced playlists operations:
    • Editing of on-Air playlists
    • Manual or automatic adding of the next playlist without stopping the current one
    • Editing of all primary and secondary events (including on-Air) properties
    • Playlist looping mode
  • Advanced operation with external control GPI/ DTMF/SCTE-104 signals
  • Open format of reports for integration with media planning systems
  • Creation of Air playlist backup copy on the tape
  • As run log report for each Air channel
  • Possibility to export log reports to files of spreadsheet formats

Specifications

DATA BASE:
MS SQL Server

GRAPHICS:
Import
 AVI 32bit, TGA 32 bit, TPJ
Storage TPJ

VIDEO:
Import
AVI, MOV, MXF, DV, DIF, M2V, MTS, MP4, M2P, M2TS, M2T, MPG, WAV
Storage AVI, MOV, MXF, MP4
Export AVI, MOV, MXF, MP4
Project export as XMLAdobe Premiere, Apple Final Cut Pro, GV Edius

SUBTITLES:
Import / Export
 ASB, STL, XIF, SRT

SYSTEMS:

Videoservers Azimuth

Formats
SD 720х576, 50i/25p
HD 1920х1080, 50i/25p
UHD 3840х2160, 25p

Video 3G/HD/SD-SDI

Audio SDI Embedded, AES Unbalanced

IP SMPTE ST2110, SMPTE ST2022

IP multicast: mpeg4 h.264/ mpeg2 h.263

Cross conversion HD/SD

IP preview

Files AVI, MOV, MXF, MP4

Videotape Recorder RS-422A

Graphics server Azimuth, Carrot, Miranda, VizRT

Subtitles generator Azimuth

Formats SD: ETS 300 706; HD: OP-47
